Aprašymas

• Įrenginiai ir Ištekliai
• Vaizdo Valdymas32ch by default,can be expanded into 128ch (Including ANPR Cameras and Cameras with Face Capture Function)
• Prieigos Kontrolė4ch by default,can be expanded into 16ch (Including Doors and Outdoor Station)
• Vidaus StotisNot included,can be expanded into 16
• ANPR KamerosNot included,can be expanded into 16ch
• Lanes of Entrance & ExitNot included,can be expanded into 16
• Kameros su Veido Fiksavimo FunkcijaNot included,can be expanded into 16ch
• Signalizacijos SkydelisNot included,can be expanded into 16
• Išmaniosios SienosNot included
• LankomumasNot included,can be expanded by extra license

• Veikimas
• Įvykių ar Signalizacijų Saugojimas be Nuotraukų10/s
• Įvykiai ar Signalizacijos Siunčiami Klientams10/s，10 Client/s (Including Control Clients and Mobile Clients）
• Nuotraukų Saugojimas10/s (Including event/alarm pictures, face pictures, and vehicle pictures)
• Transporto Priemonių Praėjimo Dažnis Kiekvienoje Juostoje1 Vehicle/s
• Data Retention Period Stored for 6 Months

• Dekodavimo Veikimas
• 4CIF (704*576)/H.264/1024 kbps * 30 fps

  Maximum Hardware Decoding Channels：62

  Maximum Software Decoding Channels：42

• 4CIF (704*576)/H.265/512 kbps * 30 fps

  Maximum Hardware Decoding Channels：62

  Maximum Software Decoding Channels：42

• 720P (1280*720)/H.264/2048 kbps * 30 fps

  Maximum Hardware Decoding Channels：42

  Maximum Software Decoding Channels：24

• 720P (1280*720)/H.265/1024 kbps * 30 fps

  Maximum Hardware Decoding Channels：42

  Maximum Software Decoding Channels：24

• 1080P (1920 × 1080)/H.264/4096 kbps * 30 fps

  Maximum Hardware Decoding Channels：32

  Maximum Software Decoding Channels：16

• 1080P (1920 × 1080)/H.265/2048 kbps * 30 fps

  Maximum Hardware Decoding Channels：32

  Maximum Software Decoding Channels：16

• 4 MP (2560 × 1440)/H.264/8192 kbps * 30 fps

  Maximum Hardware Decoding Channels：24

  Maximum Software Decoding Channels：10

• 4 MP (2560 × 1440)/H.265/4096 kbps * 30 fps

  Maximum Hardware Decoding Channels：24

  Maximum Software Decoding Channels：10

• 8 MP (3840 × 2160)/H.264/16384 kbps * 30 fps

  Maximum Hardware Decoding Channels：12

  Maximum Software Decoding Channels：5

• 8 MP (3840 × 2160)/H.265/8192 kbps * 30 fps

  Maximum Hardware Decoding Channels：12

  Maximum Software Decoding Channels：5

• 6 MP (2560 × 2560) /H.264/12288 kbps * 30 fps

  Maximum Hardware Decoding Channels：18

  Maximum Software Decoding Channels：8

• 6 MP (2560 × 2560) /H.265/6144 kbps * 30 fps

  Maximum Hardware Decoding Channels：18

  Maximum Software Decoding Channels：8

• 12 MP (4000 × 4000)/H.264/16384 kbps * 20 fps

  Maximum Hardware Decoding Channels：10

  Maximum Software Decoding Channels：4

• 12 MP (4000 × 4000)/H.265/8192 kbps * 20 fps

  Maximum Hardware Decoding Channels：10

  Maximum Software Decoding Channels：4

• Hardware Specifications
• CPUi5-12500， 3.00 GHz, 18 MB Cache， 6 Cores, 12 Threads
• Atmintis

  Standard Config：2 × 8GB UDIMM，3200MT/s

  Scalability：4 × 32GB UDIMM

• Kietieji Diskai

  Standard Config：1 × 1TB M.2 SSD

  Scalability：1 × 4TB 3.5inch SATA HDD

• Palaikomos Operacinės SistemosWin10 multilingual version pre-installed
• Grafikos Kortelė

  Standard Config：UHD Graphics 770（intergrated in CPU）

  Scalability：1 × Semi-high Independent graphics card（Please contact technical support for more info.）

• PCIe Lizdai1*PCIe 4.0 x16 Slot 1*PCIe 4.0 x4 Slot

• Prievadai
• Type-C1
• USB 3.01（Front）+3（Rear）
• USB 2.02（Front）+2（Rear）
• Universalus Garso Prievadas1
• Eternetinis Prievadas1 x LAN 10/100/1000
• VGA/（HDMI port can be used as VGA port）
• HDMI1
• DP3（DP port can be used as HDMI port）

• Pagrindinis
• Svoris be įpakavimo5.63 kg (12.42 lb)
• Svoris su įpakavimo6.72 kg (14.81 lb)
• Dydis92.60 mm × 290.00 mm × 292.80 mm (3.65” × 11.42” × 11.53”)
• Pakuotės Matmenys (P × A × G)394.00 mm × 264.00 mm × 487.00 mm (15.51” × 10.39” × 19.17”)
• Darbo sąlygos (temperatūra)5 °C to 45 °C (41 °F to 113 °F)
• Sandėliavimo sąlygos temperatūra-40 °C to 70 °C (-40 °F to 158 °F)
• Darbo sąlygos (drėgmė)20% to 80% (no condensation)
• Sandėliavimo sąlygos drėgmė5% to 95% (no condensation)
• Maitinimas300 W PSU，92% Energy efficiency，80 Plus Platinum
• Form FaktoriusTower SFF
