Aprašymas

• Bendrieji duomenys
• Nominal power (VA)6000
• Active power (W)6000
• TechnologijaOn-Line Double Conversion VFI-SS-111
• Bangos formaSinusoidal
• UPS architectureConvertible tower and rack 19″
• Surge Rating1900
• ECO Mode efficiency98%
• Įvesties įtampa230 V
• Įvesties dažnis50-60 Hz ±5% Autosensing
• Įėjimo įtampos diapazonas170V – 288V on full load
• THD Input current< 3%
• Input power factor> 0.99
• Išėjimo įtampa230V ± 1%
• Output frequency (nominal)50/60 Hz (settable from LCD panel) ± 0.1%
• Crest Factor1:3
• THD Output voltageLinear load 2%, Nonlinear load 5%
• Output Voltage Tolerance±1%
• Uptime ExpansionNo
• Baterijų skaičius20
• Battery series Type/Voltage12V 5Ah
• Uptime with 80% load (min)4
• Display and SignalsFour buttons and four LEDs to monitor UPS status in real time
• Ryšio prievadaiRS232 serial ports, USB
• Remote ManagementAvailable
• Network interface slotSNMP
• Measurements H x L x D (mm)440 x 176 (4U) x 680
• Battery Cabinet Measurements H x L x D (mm)440 x 132 (3U) x 680
• Svoris (kg)60
• Operating temperature (°C)0 ÷ 40 °C
• Degree of protectionIP20
• Relative humidity (%)0-95% non-condensing
• Noise level at 1 m (dBA)< 50
• Heat Loss (BTU/h)1300
• SertifikataiEN 62040-1, EN 62040-2, EN 62040-3
