Aprašymas

• Specifikacijos
• Bendras prievadų skaičius:2 PoE Ports, 2 BNC Ports (female)
• PoE IN:LAN/LAN + PoE IN 802.3af/at, PoE Passive
• PoE OUT:LAN/LAN + PoE OUT 802.3af/at/bt60
• PoE IN/OUT:LAN/LAN + PoE IN, LAN/LAN + PoE OUT
• LAN 10/100Mbps prievadai:LAN/LAN + PoE OUT
• Įėjimo įtampa:10 … 58 V (for powering PoE receivers Vin>44V DC)
• Išėjimo PoE įtampa:Vout = Vin (44… 58 V)
• Maximum output power from the port:LAN/LAN + PoE OUT – 60 W
• Energijos suvartojimas:1,35 W (full channel)
• Išėjimo galios valdymas:Auto-negotiation
• Viršįtampio apsauga:LAN and BNC Ports
• Apsauga nuo perkrovos:xCOAX4-SW – Short circuit protection with auto recovery
• Length of coaxial cable:< 1000m – xCOAX4-SW to xCOAX4-CAM
• Coaxial track signalling:LED LINK at the BNC connector (green) – link and data transmission in the COAX channe
• Energijos indikacija:LED PWR – Power presence
• PoE indikacija:LED port RJ45 (yellow) – PoE Power
• Perdavimo indikacija:LED port RJ45 (green) – link and data transmission LED LINK at the BNC connector (green) – link and data transmission in the COAX channel
• LAN pralaidumo indikacija:LED 10Mb – LAN transmission in the XCOAX channel at a speed of 10Mbps
• Žemos įtampos indikacija:LED LV Low Voltage signaling diode
• Temperatūros diapazonas:-25°C … +65°C
• Matmenys:51(73) x 51 x 23 mm
• Svoris:0,06 kg
• IP klasė:IP20
• Korpuso konstrukcija:Uniwersal mounting base
• Surinkimas:Mounting studs, TH35 rail with additional bracket, can be screwed to flat surface
• EAN kodas:5902143691464
• PKWiU kodas:26.30.23.0
• HS kodas:8517 62
• CN2020 kodas:8517 62 00
