Aprašymas

• Vaizdas ir garsas
• IP vaizdo įrašų įvestis

  64-ch

  Up to 12 MP resolution

  *: 32 MP and 24 MP is only available for channel 1 when ultra HD resolution mode is enabled. For DS-9632NI-I16, when ultra HD resolution mode is enabled, it will reduce the IP video input to 24-ch.

• Įeinantis pralaidumas320 Mbps
• Išeinantis pralaidumas256 Mbps
• Incoming Bandwidth (RAID Mode)200 Mbps
• Outgoing Bandwidth (RAID mode)200 Mbps
• HDMI 1 Output4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
• HDMI 2 Output1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
• VGA 1 Output1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
• VGA 2 Output1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
• Vaizdo išvesties režimas

  HDMI 1 and VGA 1 provide simultaneous video output, and work as the main output;

  HDMI 2 and VGA 2 provide simultaneous video output, and work as the auxiliary output

• CVBS išvestis1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
• Garso įvestis1-ch, RCA (2.0 Vp-p, 1 KΩ)
• Garso išvestis2-ch, RCA (Linear, 1 KΩ)
• Dvipusis greitis1-ch, RCA (2.0 Vp-p, 1 k Ω)

• Iškodavimas
• Vaizdo iškodavimo formatasH.265/H.265+/H.264/H.264+/MPEG4
• Įrašymo raiška

  32 MP/24 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF /2CIF/CIF/QCIF

  *: 32 MP and 24 MP is only available for channel 1 when ultra HD resolution mode is enabled. For DS-9632NI-I16, when ultra HD resolution mode is enabled, it will reduce the IP video input to 24-ch.

• Sinchroninis atkūrimas16-ch
• Iškodavimo pajėgumas1-ch@32 MP (30 fps)/2-ch@12 MP (20fps)/4-ch@8 MP (25fps)/8-ch@4 MP (30fps)/16-ch@1080p (30fps)
• Dviejų srautų įrašymasRamstis
• Srauto tipasVideo, Video & Audio
• Garso suspaudimasG.711ulaw/G.711alaw/G.722/G.726/AAC/MP2L2/PCM

• Internetas
• Nuotolinis prisijungimas128
• ProtokolaiTCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
• Tinklo sąsaja2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface

• RAID
• RAID TypeRAID0, RAID1, RAID5, RAID6, and RAID10 (at least 4 TB for each HDD)

• Sąsajos
• Serijinė sąsaja1 RS-485 (full-duplex), 1 RS-232, 1 keyboard
• SATA16 SATA interfaces supporting hot-plug
• eSATA1 eSATA interface
• TalpaUp to 10TB capacity for each disk
• Ispėjamojo signalo įvestis/išvestis16/8
• USB sąsajaFront panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0

• Pagrindinis
• Maitinimas100 to 240 VAC, 50 to 60 Hz
• Energijos sunaudojimas≤ 45 W
• Darbinė temperatūra-10 °C to 55 °C (14 °F to 131 °F)
• Atsparumas drėgmei10 to 90 %
• Korpusas3U chassis
• Dydis445 × 496 × 146 mm (17.5″ × 19.5″ × 5.7″)
• Svoris≤ 12.5 kg (27.6 lb)

• Sertifikatai
• FCCPart 15 Subpart B, ANSI C63.4-2014
• CEEN 55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4
