Aprašymas

• Judesio aptikimas 2.0
• Žmogaus / transporto priemonės analizė

  Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights;

  Quick search by object or event type is supported;

• Perimetro apsauga
• Žmogaus / transporto priemonės analizėUp to 2-ch

• Įrašymas
• Vaizdo suspaudimasH.265 Pro+/H.265 Pro/H.265/H.264+/H.264
• Užkodavimo raiška

  When 1080p Lite mode is not enabled:

  4 MP Lite/3 MP/1080p/720p/VGA/WD1/4CIF/CIF;

  When 1080p Lite mode is enabled:

  4 MP Lite/1080p Lite/720p Lite/VGA/WD1/4CIF/CIF

• Kadrų skaičius

  Main stream:

  When 1080p Lite mode is not enabled:

  For 4 MP stream access:

  4 MP Lite@15 fps; 1080p Lite/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N)

  For 3 MP stream access:

  3 MP/1080p/720p/VGA/WD1/4CIF/CIF@15 fps

  For 1080p stream access:

  1080p/720p@15 fps; VGA/WD1/4CIF/CIF@25fps (P)/30 fps (N)

  For 720p stream access:

  720p/VGA/WD1/4CIF/CIF@25 fps (P)/30 fps (N)

  When 1080p Lite mode is enabled:

  4 MP Lite@15 fps; 1080p Lite/720p Lite/VGA/WD1/4CIF/CIF@25 fps (P)/30 fps (N)

  Sub-stream:

  WD1/4CIF@12 fps; CIF@25 fps (P)/30 fps (N)

• Video Bitrate32 Kbps to 6 Mbps
• Dvibugas srautasSupport
• Srauto tipasVideo, Video & Audio
• Garso suspaudimasG.711u
• Garso bitų greitis64 Kbps

• Vaizdas ir garsas
• IP vaizdo įrašų įvestis

  1-ch (up to 5-ch)

  Enhanced IP mode on:

  2-ch (up to 6-ch), each up to 4 Mbps

  Up to 6 MP >rezoliucija

  Support H.265+/H.265/H.264+/H.264 IP cameras

• Analoginė vaizdo įrašų įvestis

  4-ch

  BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection

• HDTVI įvestis

  4 MP, 3 MP, 1080p25, 1080p30, 720p25, 720p30, 720p50, 720p60

  *: The 3 MP signal input is only available for channel 1.

• AHD įvestis4 MP, 1080p25, 1080p30, 720p25, 720p30
• HDCVI įvestis4 MP, 1080p25, 1080p30, 720p25, 720p30
• CVBS įvestisSupport
• HDMI išvestis1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
• VGA išvestis1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
• Vaizdo išvesties režimasHDMI/VGA simultaneous išvestis
• Garso įvestis

  1-ch, RCA (2.0 Vp-p, 1 KΩ)

  4-ch via coaxial cable

• Garso išvestis1-ch, RCA (Linear, 1 KΩ)
• Dvipusis greitis1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)
• Sinchroninis atkūrimas4-ch

• Internetas
• Total Bandwidth72 Mbps
• Nuotolinis prisijungimas32
• ProtokolaiTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
• Tinklo sąsaja1, RJ45 10/100 Mbps self-adaptive Ethernet jungtis
• Wi-FiConnectable to Wi-Fi network by Wi-Fi dongle through USB jungtis

• Sąsajos
• SATA1 SATA interface
• TalpaUp to 10 TB capacity for each disk
• Ispėjamojo signalo įvestis/išvestisN/A
• USB sąsajaReal panel: 2 × USB 2.0

• Pagrindinis
• Maitinimas12 VDC, 1.5 A
• Energijos sunaudojimas≤ 8 W (without HDD)
• Darbinė temperatūra-10 °C to +55 °C (+14 °F to +131 °F)
• Atsparumas drėgmei10% to 90%
• Dydis200 × 200 × 45 mm (7.9 × 7.9 × 1.8 inch)
• ≤ 1 kg (without HDD, 2.2 lb.)
