Aprašymas

• Patvirtinimai
• EMCCE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021, IC: ICES-003: Issue 7,KC: KN32: 2015, KN35: 2015
• AplinkosaugaCE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006
• ApsaugaIP67: IEC 60529-2013
• SaugumasCB: IEC 62368-1: 2014+A11,BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005

• Garsas
• Garso bitų dažnis64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)
• Audio Compression G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC
• Garso atrankos dažnis8 kHz/16 kHz
• Garso tipasMono sound
• Pašalinių garsų šalinimasYes

• Camera
• Kampo keitimasPan: 0° to 360°,tilt: 0° to 180°,rotate: 0° to 360°
• Diena&NaktisIR cut filter
• Vaizdo jutiklis1/2.5″ Progressive Scan CMOS
• Didžiausia raiška3632 × 1632
• Minimalus apšvietimasColor: 0.005 Lux @ (F1.6, AGC ON)
• Užrakto greitis1 s to 1/100,000 s

• DORI
• DORI2.8 mm, D: 42 m, O: 16 m, R: 8 m, I: 4 m

• Funkcijos
• Basic Event Motion detection (support alarm triggering by specified target types (human and vehicle)),exception
• SąsajaUpload to FTP/memory card, send email, notify surveillance center, trigger recording, trigger capture, audible warning, strobe light flashing

• Bendra informacija
• Matmenys103.6 mm × 76 mm × 234.5 mm (4.1″ × 3.0″ × 9.2″)
• Flashing Light/SRB model: Red and Blue Light/SL model: White Light
• Pagrindinės funkcijosHeartbeat,anti-banding,password protection,password reset via email
• KalbaEnglish, Turkish, Polish, Romanian, Czech, Slovak, Traditional Chinese, Thai, Vietnamese, Croatian, Slovenian, Serbian, Ukrainian
• MedžiagaFront cover: Metal, body: Plastic, bracket: Metal
• Pakuotės dydis260 mm × 140 mm × 115 mm (10.2″ × 5.5″ × 4.5″)
• Energija12 VDC ± 25%, 0.83 A, max. 10 W,Ø5.5 mm coaxial power plug,reverse polarity protection,PoE: IEEE 802.3af, Class 3, max. 11.5 W
• Darbo sąlygos-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
• Sandėliavimo sąlygos-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
• SvorisApprox. 560 g (1.2 lb.)
• Svoris su įpakavimuApprox. 835 g (1.8 lb.)

• Apšvietimas
• IR bangos ilgis850 nm
• Išmanus papildomas apšvietimasYes
• Papildomo apšvietimo diapazonasUp to 30 m
• Papildomo apšviešimo tipasIR,White Light

• Nuotrauka
• Dienos/nakties perjungiklisDay,Night,Auto,Schedule
• Nuotraukų pagražinimasBLC,HLC,3D DNR
• Vaizdo nustatymaiRotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
• Privatumo kaukė4 programmable polygon privacy masks
• SNR≥ 52 dB
• Wide Dynamic Range (WDR)120 dB

• Sąsaja
• Integruotas mikrofonasYes,1 built-in microphone
• Integruotas garsiakalbisYes, 1 built-in speaker,Max. power consumption: 2 W, max. sound pressure level: 10 cm: 97 dB.
• Interneto sąsaja1 RJ45 10 M/100 M self-adaptive Ethernet port
• Vidinė atmintisBuilt-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
• Perkrovimo mygtukasYes

• Objektyvas
• DiafragmaF1.6
• Focal Length & FOV2.8 mm, horizontal FOV 180°, vertical FOV 77°
• Rainelės tipasFixed
• Objektyvo tvirtinimasM12
• Objektyvo tipasFixed focal lens, 2.8 mm

• Tinklas
• APIONVIF (Profile S, Profile T, Profile G),ISAPI,SDK
• KlientasiVMS-4200,Hik-Connect
• ProtokolaiTCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IPv4, IPv6, IGMP, UDP, QoS, FTP, SMTP
• SaugumasPassword protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address)
• Tiesioginis vaizdo žiūrėjimasUp to 6 channels
• Naudotojas/prievadasUp to 32 users3 user levels: administrator, operator, and user
• NaršyklėPlug-in required live view: IE 11,Local service: Chrome 80+, Firefox 80+, Edge 89+

• Vaizdas
• Bitų dažnio valdymasCBR,VBR
• H.264 tipasBaseline Profile,Main Profile,High Profile
• H.265 tipasMain Profile
• Pagrindinis srautas50 Hz: 20 fps (3632 × 1632)60 Hz: 20 fps (3632 × 1632)
• Region of Interest (ROI)1 fixed region for main stream
• Scalable Video Coding (SVC)H.264 and H.265 encoding
• Antrinis srautas50 Hz: 20 fps (1200× 536, 960 × 432)60 Hz: 20 fps (1200× 536, 960 × 432)
• Vaizdo bitų dažnis32 Kbps to 16 Mbps
• Video Compression Main stream: H.265+/H.265/H.264+/H.264,Sub-stream: H.265/H.264/MJPEG
