Aprašymas

• Bendravimas
• Jeweller ryšio technologijaProprietary wireless communication technology to transmit commands, alarms, and events., Key features:, Two-way communication., Advanced sabotage protection., Block encryption featuring a dynamic key., Instant notifications., Remote configuration in the Ajax apps., Learn more
• Dažnių juostos866.0–866.5 MHz 868.0–868.6 MHz 868.7–869.2 MHz 905.0–926.5 MHz * 915.85–926.5 MHz 921.0–922.0 MHz, Depends on the sales region., * Certified according to UL/ULC standards.
• Maksimali efektyvi spinduliuojama galia (ERP)up to 20 mW, Automatic power control to reduce power consumption and noise interference.
• Radijo signalo moduliacijaGFSK
• Radijo signalo veikimo nuotolisup to 1,000 ft, Between the panic button and control panel (or range extender) in an open space. Locate DoubleButton in a place with stable Jeweller signal strength (2-3 bars in the Ajax app)., Calculate the radio signal range at the facility
• Šifruotas ryšysAll the data stored and transmitted are protected by block encryption with a dynamic key.
• Dažnių šuoliaiRadio communication uses frequency hopping to prevent interception and jamming., Learn more

• Pagrindinės savybės
• Mygtukų skaičius2
• Apsauga nuo atsitiktinio paspaudimoboth buttons pressing protective plastic divider
• Pavojaus signalo patvirtinimaswith one DoubleButton or several, To raise a confirmed alarm (hold-up event), you need to perform the selected action., How to set up an alarm confirmation for the hold-up device
• LED apšvietimas, rodantis komandos pristatymąThe LED brightness is adjusted in Ajax apps.
• Pavojaus scenarijusby the DoubleButton pressing, The control mode for automation devices is not supported., How to configure the scenario by alarm

• Apsauga nuo sabotažo
• Apsauga nuo klastojimodevice authentication

• Maitinimas
• Baterija1 × CR2032, Pre-installed.
• Apskaičiuotas baterijos veikimo laikasup to 5 years
• Įrenginio darbinės įtampos diapazonas1.8−3.3 V⎓
• Nominali įrenginio darbinė įtampa3 V⎓
• Ramioji įrenginio srovės sąnauda esant nominaliai įtampai0.54 μA
• Maksimali įrenginio srovės sąnauda esant nominaliai įtampai34.8 mA
• Pilna baterijos talpa235 mAh
• Maža baterijos įtampa2.2 V⎓
• Mažos baterijos atsigavimo įtampa2.3 V⎓
• Galutinė baterijos įtampa1.8 V⎓, Device is switched off.
• Galutinė baterijos talpa40 mAh
• GamintojasPanasonic, UL listed.

• Korpusas
• Matmenys1.85″ × 1.38″ × 0.63″
• Svoris0.60 oz
• Darbo temperatūros diapazonasfrom 14 °F to 104 °F, Temperature range from 32 °F (0 °C) to 120 °F (49 °C) is certified according to UL/ULC standards.
• Drėgmėup to 75%, Humidity up to 85% is certified according to UL/ULC standards.
• Apsaugos klasėIP55
