Aprašymas

• Patvirtinimai
• Cheminių komponentų sertifikavimasCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No.1907/2006)
• EMCCE-EMC (EN 55032: 2015+A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035: 2017+A11: 2020); IC (ICES-003: Issue 7:2020); RCM (AS/NZS CISPR 32: 2015)
• RadioEN 301 893; EN 300 440; EN 62311; EN 301 489-3; EN 301 489-17; FCC Part 15.247
• SaugumasUL (UL 60950-1); CB (AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition); CE-LVD (EN 62368-1: 2014+A11: 2017)

• Bendrieji duomenys
• Bendras svoris0.807 kg (1.779 lb)
• Installation ModePole mounting
• Grynas svoris0.307 kg (0.677 lb)
• Pakuotės Matmenys (P × A × G)132 mm × 228 mm × 91 mm (5.19″ × 8.97″ × 3.58″)
• PakuotėjeWireless bridge × 1, power adapter (12 VDC, 1 A) × 1, 1000 MB PoE injector × 1, binding tape × 2, quick start guide × 1
• Packing MethodSingle unit packing
• Energijos suvartojimas3 W for typical (1-ch 2MP IPC), Max. 7.5 W
• Produkto matmenys (P × A × G)92 mm × 187 mm × 58 mm (3.62″ × 7.36″ × 2.28″)
• Laikymo drėgnumas5% to 95% (no condensation)
• Laikymo temperatūra-40°C to 85°C (-40°F to 185°F)
• Darbinė drėgmė5% to 95% (no condensation)
• Darbinė temperatūra-30°C to 70°C (-22°F to 158°F)

• Hardware Parameter
• LED indikatoriusPower indicator, LAN indicator, signal intensity indicator
• Port Numbers2 × Gigabit RJ45 ports
• Energijos šaltinis12 VDC/1 A Passive PoE; 12 VDC, 1 A
• PerkrovimasHardware resetting button

• Tinklo parametrai
• Networking ModePoint to point: Support up to 4-ch IPC (2MP) in Max. 15 KM distance and Max. 20 Mbps bandwidth,Point to point: Support up to 40-ch IPC (2MP) in Max. 5 KM distance and Max. 200 Mbps bandwidth,Point to multi-point: Support up to 16-ch IPC (2MP) in Max. 5 KM distance and Max. 80 Mbps bandwidth within 30°, Max. 1 to 8 PTMP connection

• Programinės įrangos funkcijos
• Application FunctionTDMA, DFS, TPC,IFM,IPM
• Channel SelectionAuto/manual selection
• Kanalo plotis20/40/80 MHz
• Management MethodWeb, HCP
• ProtokolaiNTP (network time synchronization), SADP (auto search for IP address), HTTPS (web management), SSH (debugging)
• Security MechanismWireless network name hidden
• Security ModeWPA2-PSK
• Sistemos žurnalasSyslog, control center information
• UpgradeWeb, iVMS-4200

• Belaidžio ryšio parametrai
• Antenna AngleBeamwidth [3dB] (35°± 5°)
• Antenos stiprinimas12 dBi
• Max. Transmission Rate of Air Interface≤ 867 Mbps
• Receiving Sensitivity-60 ± 2 dBm@AC80 -MCS9; -86 ± 2 dBm@AC80 -MCS0
• Perdavimo galia27 dBm (Note: Transmitting power may vary with local regulations.)
• Belaidžio ryšio standartasIEEE 802.11/a/n/ac
• Working Frequency Band5150 to 5250 MHz5250 to 5350 MHz (DFS)5470 to 5725 MHz (DFS)5725 to 5850 MHz(Note: Available channel may vary with local regulations.)
