Aprašymas

• Pagrindinis
• Product Dimensions (W × H × D)92 mm × 187 mm × 58 mm (3.62” × 7.36” × 2.28”)
• Pakuotės Matmenys (P × A × G)132 mm × 228 mm × 91 mm (5.19″ × 8.97″ × 3.58″)
• Svoris be įpakavimo0.307 kg (0.677 lb)
• Svoris su įpakavimo0.807 kg (1.779 lb)
• PakuotėjeWireless Bridge × 1,Power Adapter (12 VDC, 1 A) × 1,Binding Tape × 2,Quick Start Guide ×1
• Packing MethodSingle unit packing
• Darbinė temperatūra-30 °C to 70 °C (-22 °F to 158 °F)
• Atsparumas drėgmei5% to 95% (no condensation)
• Sandėliavimo sąlygos temperatūra-40 °C to 85 °C (-40 °F to 185 °F)
• Sandėliavimo sąlygos drėgmė5% to 95% (no condensation)
• Installation ModePole Mounting
• Ingress ProtectionIP55
• Energijos sunaudojimas2.65 W for typical (1-ch 2MP IPC), Max. 4.5 W

• Belaidžio ryšio parametrai
• Throughput RatePoint to point: Support up to 4-ch IPC (2MP) in Max. 5 KM distance and Max. 20 Mbps bandwidth,Point to point: Support up to 40-ch IPC (2MP) in Max. 1 KM distance and Max. 200 Mbps bandwidth,Point to multi-point: Support up to 16-ch IPC (2MP) in Max. 1 KM distance and Max. 80 Mbps bandwidth within 30°, Max. 1 to 8 PTMP connection
• Max. Transmission Rate of Air Interface≤ 867 Mbps
• Belaidis standartasIEEE 802.11/a/n/ac
• Working Frequency Band5150 MHz ~ 5250 MHz,5250 MHz~ 5350 MHz,5470 MHz~ 5725 MHz,5725 MHz~ 5850 MHz
• Antenos stiprinimas12 dBi
• Antenna Angle(H) Beamwidth [3 dB] 35° (V) Beamwidth [3 dB] 35°
• Transmitting Power22 dBm (Note: Transmitting power may vary with local regulations.)
• Receiving Sensitivity-58±2 dBm@AC80-MCS9,-84±2dBm@AC80-MCS0

• Hardware Parameter
• Maitinimas12 VDC/1 A Passive PoE
• Tinklo sąsaja2 × 1000 Mbps RJ45 ports
• LED indikatoriusPower indicator,LAN indicator,Signal intensity indicator
• PerkrovimasHardware resetting button

• Programinės įrangos funkcijos
• Application FunctionTDMA,DFS,TPC,IFM,IPM
• Kanalo plotis20/40/80 MHz
• Channel SelectionAuto/manual selection
• ProtokolaiNTP (network time synchronization),SADP (auto search for IP address),HTTPS (web management),SSH (debugging)
• Security ModeWPA2-PSK
• Security MechanismWireless network name hidden
• Management MethodWeb,iVMS-4200,HCP
• UpgradeWeb,iVMS-4200,HCP
• System LogSyslog,Control center information

• Patvirtinimai
• EMCCE-EMC (EN 55032: 2015+A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035: 2017+A11: 2020),IC (ICES-003: Issue 7:2020),RCM (AS/NZS CISPR 32: 2015)
• SaugumasUL (UL 60950-1),CB (AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition), CE-LVD (EN 62368-1: 2014+A11: 2017)
• Cheminis tyrimasCE-RoHS (2011/65/EU),WEEE (2012/19/EU),Reach (Regulation (EC) No.1907/2006)
• RadioEN 301 893,EN 300 440,EN 62311,EN 301 489-3,EN 301 489-17,FCC Part 15.247
