Aprašymas

• Judesio aptikimas 2.0
• Žmogaus / transporto priemonės analizė

  Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights;

  Quick search by object or event type is supported;

• Perimetro apsauga
• Žmogaus / transporto priemonės analizėUp to 2-ch

• Facial Detection
• Facial Detection and CaptureFace picture detection, face picture search

• Vaizdas ir garsas
• IP vaizdo įrašų įvestis

  1-ch (up to 5-ch）

  Up to 6 MP resolution

  Enhanced IP mode on:

  2-ch (up to 6-ch), each up to 4 Mbps

  Support H.265+/H.265/H.264+/H.264 IP cameras

• Analoginė vaizdo įrašų įvestis4-ch;BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
• HDMI išvestis

  1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz,

  HDMI/VGA simultaneous output

• CVBS InputPAL/NTSC
• CVBS išvestis

  1-ch, BNC (1.0 Vp-p, 75 Ω),

  resolution: PAL: 704 × 576, NTSC: 704 × 480

• Sinchroninis atkūrimas4-ch
• HDTVI Input3K(2960 x 1665)@20 fps, 5 MP(2560 × 1944)@20 fps, 4 MP(2560 × 1440)@30 fps, 4 MP(2560 × 1440)@25 fps,1080p@30 fps, 1080p@25 fps,720p@30 fps, 720p@25 fps
• AHD Input5 MP(2592 × 1944)@20 fps,4 MP(2560 × 1440)@30 fps, 4 MP(2560 × 1440)@25 fps, 1080p@30 fps, 1080p@25 fps, 720p@30 fps, 720p@25 fps
• VGA išvestis1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
• HDCVI Input5 MP(2592 × 1944)@20 fps,4 MP(2560 × 1440)@30 fps, 4 MP(2560 × 1440)@25 fps, 1080p@30 fps, 1080p@25 fps, 720p@30 fps, 720p@25 fps
• Garso išvestis1-ch, RCA (Linear, 1 KΩ)
• Garso įvestis1-ch, RCA (2.0 Vp-p, 1 KΩ),4-ch via coaxial cable
• Dvipusis greitis1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)

• Įrašymas
• Vaizdo suspaudimasH.265 Pro+/H.265 Pro/H.265/H.264+/H.264
• Užkodavimo raiška

  When 1080p Lite mode is not enabled:

  3K lite/5 MP lite/4 MP lite/1080p/720p/VGA/WD1/4CIF/CIF;

  When 1080p Lite mode is enabled:

  3K lite/5 MP lite/4 MP lite/1080p lite/720p lite/VGA/WD1/4CIF/CIF

• Kadrų dažnis

  Main stream:

  When 1080p Lite mode not enabled:

  For 3K stream access: 3K lite@12fps;4 MP lite/1080p@15fps;720p/WD1/4CIF/VGA/CIF@20fps

  For 5 MP stream access: 5 MP lite@12fps;4 MP lite/1080p@15fps;720p/WD1/4CIF/VGA/CIF@20fps

  For 4 MP stream access: 4 MP lite/1080p@15fps;720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)

  For 1080p stream access: 1080p/720p@15fps; VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)

  For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)

  When 1080p Lite mode enabled:

  3K lite/5 MP lite@12fps;4 MP lite@15fps;1080p lite/720p lite/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)

  Sub-stream:

  WD1/4CIF@12fps; CIF@25fps (P)/30fps (N)

• Video Bitrate32 Kbps to 6 Mbps
• Dvibugas srautasSupport
• Srauto tipasVideo, Video & Audio
• Garso suspaudimasG.711u
• Garso bitų greitis64 Kbps

• Internetas
• Total Bandwidth72 Mbps
• ProtokolaiTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
• Nuotolinis prisijungimas32
• Tinklo sąsaja1, RJ45 10M/100M self-adaptive Ethernet interface

• Sąsajos
• SATA1 SATA interface
• TalpaUp to 10 TB capacity for each disk
• Serijinė sąsajaRS-485 (half-duplex)
• USB sąsaja2 × USB 2.0
• Ispėjamojo signalo įvestis/išvestisN/A

• Pagrindinis
• Maitinimas12 VDC, 1.5A
• Energijos sunaudojimas≤ 18 W
• Darbinė temperatūra-10 °C to +55 °C (+14 °F to +131 °F)
• Atsparumas drėgmei10% to 90%
• Dydis315 × 242 × 45 mm (12.4 × 9.5 × 1.8 inch)
• Svoris≤ 1.16 kg (2.6 lb)
