Aprašymas
- Bendra informacija
- Matmenys442.4 × 43.7 × 496 mm (17.4 × 1.7 × 19.5″)
- Port Layout 2.5 GbE RJ458 ports (All PoE+++) (2.5G/1G/100M/10M)
- Port Layout 10 GbE RJ4516 ports (All PoE+++) (10G/5G/2.5G/1G/100M/10M)
- Port Layout 25G SFP282 ports (25G/10G/1G)
- Maksimali PoE išvestisUp to PoE+++
- Total PoE AvailabilityShared/Redundant depending on AC input (up to 2,250W shared or 1,050W redundant)
- Atsparumas gedimams(2) Hot-Swappable PSUs, (4) Hot-Swappable Fans
- Layer 3 SupportYes
- Form FaktoriusRack mount (1U)
- Etherlighting™Yes
- Komutavimo pajėgumas460 Gbps
- Bendras neblokuojantis pralaidumas230 Gbps
- Perdavimo dažnis342 Mpps
- Palaikomi VLAN1,000
- MAC adresų lentelės dydis128,000
- L3 Table Size ARP Entries128,000
- L3 Table Size IPv4 Routes256,000
- Paketų buferio dydis8 MB
- Layer 3 FeaturesDHCP Server, DHCP Relay, Inter-VLAN Routing, Static Routing
- Layer 2 FunkcijosLACP Port Aggregation, STP & RSTP, IGMP Snooping & Advanced Configurations, 802.1X Control, MAC-Based ACLs, DHCP Snooping, Rate Limiting, Flow Control, Port Isolation, Port Mirroring, Jumbo Frames, LLDP-MED, Voice VLAN, Loop Protection
- PoE prievadai24 × PoE+++ ports
- Maksimali PoE galia per prievadą90W
- Maksimalios galios sąnaudos1,50W (excluding PoE output), 2,400W (including PoE output)
- Maitinimo būdas(2) Universal AC inputs (100–240V AC, 50/60 Hz)
- Maitinimo šaltinis(2) Hot-swappable AC/DC 600W modules
- Palaikomas įtampos diapazonas100–240V AC
- Šilumos išsklaidymas511.8 BTU/hr (excluding PoE output)
- Weight Without mounting brackets9.46 kg (20.9 lb)
- Weight With mounting brackets9.56 kg (21.1 lb)
- Korpuso medžiagaSGCC steel
- Palaikomas stovo gylis482.6 mm (19″) four-post racks, 650–1,000 mm (25.6–39.4″) post depth range
- LCM ekranas1.3″ touchscreen
- Fan Method(4) Hot-swappable fan modules
- ESD/EMP apsaugaAir: ±12kV, Contact: ±12kV
- Darbinė aplinkos temperatūra-5 to 40° C (23 to 104° F)
- Darbinė aplinkos drėgmė10 to 90% noncondensing
- Etherlighting™ Ethernet/SFP28Yes
- LEDs Ethernet/SystemYes
- SertifikataiCE, FCC, IC
- Atitinka NDAA reikalavimusYes
