Aprašymas

• Bendrieji duomenys
• ModelisGS1010PS2
• Ethernet prievadai8× Gigabit PoE Ethernet Ports, 2× Uplink Gigabit Ethernet Ports, 2× Uplink Gigabit SFP Slots
• PoE StandardsIEEE802.3af (15.4W), IEEE802.3at (30W)
• Pralaidumas24 Gbps
• Paketų persiuntimo greitis17.856 Mpps
• Memory Cache448 Kbit
• MAC adresų lentelė2K
• Jumbo paketas2048 bytes
• Transfer ModeStore and forward
• Supported Network ProtocolsIEEE802.3 (10Base-T), IEEE802.3u (100Base-TX), IEEE802.3ab (1000Base-TX), IEEE802.3x (Flow control), IEEE802.3z (Gigabit Ethernet Fiber Standard)
• Industry StandardsEMS: EN61000-4-2 (ESD), EN61000-4-5 (Surge)
• Network Medium10Base-T: Cat3/4/5 UTP (≤100m), 100/1000Base-TX: Cat5 or above UTP (≤100m)
• Optical MediumMultimode: 50/125, 62.5/125, 100/140 µm; Single-mode: 8/125, 8.7/125, 9/125, 10/125 µm
• Darbo temperatūra-10~50°C
• Laikymo temperatūra-40~70°C
• Darbo drėgnumas10%~90%, non-condensing
• Laikymo drėgnumas5%~90%, non-condensing
• LED indikatoriaiPWR (Power), 1-12 Green Light (Link & Data): On = Link normal, Flashing = Data transmitting
• DIP Switch – Extend ModeOff: <100m, adaptive speed, watchdog off; On: Ports 7-8 at 10 Mbps, up to 250m, watchdog active
• Įėjimo įtampaAC 100–240V
• Power Supply Output52V 2.3A (120W)
• Gaminio dydis220×161×44.5 mm
• Package Size315×215×85 mm
• Pakuotės turinysSwitch (1x), Power cord (1x), User manual (1x)
• Specialios funkcijosUplink GbE & SFP slots, Extend mode up to 250m, PoE watchdog, PoE Port Priority, fanless metal design
